Outdoor LED Display Screen with Die Cast Aluminum Cabinet Full Color and High Brightness for Advertising
Datos del producto:
| Lugar de origen: | Guangdong, China |
| Nombre de la marca: | LEDKING or OEM & ODM |
| Número de modelo: | Se trata de un sistema de control de las emisiones de gases. |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 |
|---|---|
| Precio: | $456-476 |
|
Información detallada |
|||
| Píxel: | 5 mm, 6 mm, 6,67 mm | Densidad de píxeles: | 40000 puntos/m2, 27777 puntos/m2, 22477 puntos/m2 |
|---|---|---|---|
| configuración de píxeles: | 1R1G1B | Consumo de energía máxima: | 40W, 29W, 43W |
| Peso del panel: | 0,45 kg, 0,35 kg, 0,45 kg | Tamaño del gabinete: | 960 mm*960 mm*90 mm, 576 mm*576 mm*90 mm, 768 mm*768 mm*90 mm |
| resolución del gabinete: | 192 puntos * 192 puntos, 96 puntos * 96 puntos, 128 puntos * 128 puntos, 144 puntos * 144 puntos | El mejor ángulo de visión: | 170/120, 140/120 |
| Fuente de alimentación de la pantalla: | El valor de las emisiones de CO2 de los motores de combustión renovable es el valor de las emisiones | Capacidad de potencia máxima: | 976W/m2, 1050W/m2, 1350W/m2 |
| Actualización de la frecuencia: | 1920-3840 HZ/S | Brillo: | 5000-5500 mcd/m2, 4000-5000 cd/m2 |
| Distancia de control: | < 100M | Temperatura de funcionamiento: | -10°C ~ 45°C |
| Humedad operativa: | 10-90% | ||
| Resaltar: | Die Cast Aluminum Cabinet LED Video Wall,Full Color Outdoor LED Display Screen,High Brightness Digital Signage Billboard |
||
Descripción de producto
960×960 P5 P6.67 P8 P10 Fixed Outdoor LED Video Wall Display
Product Specifications
Module Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Panel Dimension | 320mm(W) × 160mm(H) | 192mm(W) × 192mm(H) | 320mm(W) × 160mm(H) |
| Pixel pitch | 5mm | 6mm | 6.67mm |
| Pixel Density | 40000 dot/m² | 27777 dot/m² | 22477 dot/m² |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD3535 | SMD3535 |
| Pixel resolution | 64 dot × 32 dot | 32 dot × 32 dot | 48 dot × 48 dot |
| Max power consumption | 40W | 29W | 43W |
| Panel weight | 0.45KG | 0.35KG | 0.45KG |
Cabinet Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Cabinet size | 960mm×960mm×90mm | 576mm×576mm×90mm, 768mm×768mm×90mm | 960mm×960mm×90mm |
| Cabinet Resolution | 192 dot × 192 dot | 96 dot × 96 dot, 128dot×128dot | 144dot×144dot |
| Quantity of panel | 18pcs | 9pcs, 16pcs | 18pcs |
| Hub connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Diecast aluminum cabinet | Diecast aluminum cabinet | Diecast aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best viewing angle | 170/120 | 140/120 | 140/120 |
| Screen power supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max power capacity | 976W/m² | 1050W/m² | 1350W/m² |
| Average power | 488W/m² | 525W/m² | 675W/m² |
Technical Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/8S | 1/8S | 1/6S |
| Refresh frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920-3840 HZ/S |
| Display color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 5000-5500 mcd/m² | 4000-5000 cd/m² | 4000-5000 cd/m² |
| Life span | 100000 Hours | 100000 Hours | 100000 Hours |
| Control distance | < 100M | < 100M | < 100M |
| Best viewing distance | 5-40M | 6-40M | 6-40M |
| Operating temperature | -10°C ~ 45°C | -10°C ~ 45°C | -10°C ~ 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP protective index | IP65 | IP65 | IP65 |
Most in Kinglight and 3840 refresh rate, if need to change detail
More Pixel Pitch and technical details, feel free to contact us
More Pixel Pitch and technical details, feel free to contact us
